Conway General Duty Trailers
General Duty Trailer
Trailer made for carrying small plant, these trailers are practical and strong, yet easy to tow, which, for this type of work makes them indispensable, as they are designed to support and withstand the rigours of regular loading and unloading.>
Purpose designed for mini excavators, this twin axle trailer has a bucket support fitted as standard to assist the stability of the unit when in transit.
With a loading height of just 14", the trailer is easy to load, assisted by a choice of tailgate options to suit the plant being carried. The wide stable track and standard features, such as non-slip floor and flush fitting deck rings, make transportation of such items a very safe proposition indeed.
At the same time, infill panels are available for the trailer sides, enabling it to be easily converted to a versatile general purpose trailer that can handle an even wider range of applications.
Features
- Extended "A" frame
- Hot dipped galvanised steel chassis and bodywork for durability
- Independent rubber torsion bean axle suspension
- Centralised positioning bar
- All round security rail
- Non-slip phenol coated floor
- Eye or Ball coupling
- Strong rear drop legs
- Four flush mounted deck rings
- Bucket support
- Meets D.O.T. and EC regulations
Optional Equipment
- Spare wheel
- Galvanised floor
- Spare wheel bracket
- Heavy duty galvanised mesh floor
- Ladder rack
- Winch post
Trailers Spec
| Model |
Gross |
Payload |
Internal Dimensions |
Loading |
Tyre |
Axles |
| Weight |
(approx) |
Length |
Width |
Height |
Height |
Size |
Qty. |
| GD1300S8 |
1300 kg |
950kg |
2445 mm |
1200 mm |
300 mm |
380 mm |
175R13 6pr |
1 |
| 26cwt |
19cwt |
96 ins |
48 ins |
12 ins |
15 ins |
Radial |
Braked |
| GD2000T8 |
2000kg |
1600kg |
2445 mm |
1200 mm |
300 mm |
360 mm |
140/70 R12 |
2 |
| 40cwt |
32cwt |
96 ins |
48 ins |
12 ins |
14 ins |
Radial |
Braked |
| GD2600T8 |
2600kg |
2050kg |
2445 mm |
1200 mm |
300 mm |
380 mm |
175R13 6pr |
2 |
| 52cwt |
41cwt |
96 ins |
48 ins |
12ns |
15 ins |
Radial |
Braked |
Trailer Prices
| General Duty Trailers |
GD2000T8 |
GD2600T8 |
| Price |
£1,575.00 |
£1,695.00 |
| Spare wheel fitted |
£83.00 |
£83.00 |
| Delivery |
£90.00 |
£90.00 |
| Accessories |
| Spare wheel carrier |
£10.00 |
£10.00 |
| 4' mesh tailgate ramp |
£55.00 |
£55.00 |
| Ladder rack |
£36.00 |
£36.00 |
| Infil side |
£41.00 |
£41.00 |
All Prices are subject to VAT
All accessories are supplied loose unless otherwise stated.
Prices and/or specifications may be subject to change without prior notice.
Delivery charges are applicable on all trailers unless collected direct from the factory. E&OE
